Slurry Dewatering Filtration Device Horizontal Belt Filter Vacuum Absorbing Function
Product Description:
The Horizontal Belt Filter has a counter-current wash system that ensures thorough washing of the filter cake. This system is designed to minimize the amount of wash water used, making it an efficient and cost-effective filtration solution.
The Horizontal Vacuum Belt Filter is consisted of rubber belt, vacuum box, pulley and rollers, supporting frame, filter cloth, etc. these components are formed a highly efficient equipment realizing solid and liquid separation by fully taking advantage of material gravity and vacuum drawing power.
The filtration area of the system ranges from 10-1000 m2, making it suitable for a wide range of applications.
The drive system of the filter is equipped with a variable speed drive, which allows for precise control of the filtration process.
Technical Process
| Vacuum Box Lfting Device | Vacuum box is assembled by sections, each section is connected with filtrate pipe to form a vacuum filtrate collecting system. With a lifting device of vacuum box, it is more convenience for wear belt replacement. |
| Tracking Device | Adopt cylinder or bellows to adjust the tracking of cloth automatically by switching the tracking angles. It can ensure the normal operation of cloth. |
| Tension Unit | By adjusting the tension of rubber belt to ensure the friction force of belt and no tracking happened. |
| Washing Device | Adopt countercurrent and concurrent spraying devices, which can switch to concurrent washing and countercurrent washing according to differently slurries and process requirement, which can washing the materials more completely. |
Technical Parameters:
Applications:
| Application of Materials | Liquid / Solid Ratio |
| Ciric Acid | 5/1 - 3/1 |
| Zinc Oxide | 10/1 |
| Ferromagnet | 2.5/1 - 4/1 |
| Sulphur Mine | 4/1 - 2.5/1 |
| Coal Ash | 10/1 |
| Gold Mine | 2/1 |
| Sulphuric Sludeg | 1.5/1 |
| Alumine | 5/1 - 4/1 |
| Wet Cement | 2/1 |
| Mining Tailings | 6/1 |
| ABS Resin | 10/1 |
Packing and Shipping:
UNIVEE has rich experiences of products packing, loading and delivery for mutli-transporation.
Type of Packing:
| Packed in Crate / Wooden Case / Tin Lined Wooden Case / Plywood Case. |
| Packed with fumigation package |
| Packed in plastic lorap, double bister and jute rope |
FAQ:
Q: What is the brand name of the Horizontal Belt Filter?
A: The brand name of this product is UNIVEE.
Q: What is the model number of the Horizontal Belt Filter?
A: The model number of this product is U-HVBF.
Q: Where is the Horizontal Belt Filter manufactured?
A: The Horizontal Belt Filter is manufactured in China.
Q: What is the capacity of the Horizontal Belt Filter?
A: The capacity of this product varies depending on the specific model. Please refer to the product specifications for more information.
